Metal quick couplings
Beiruote Product’s material of metal quick coupling includes Stainless Steel and Chrome-plated brass. It provide a durable and economical solution for meeting in withstand higher pressure and temperature requirement applications, and a one-hand operation for swift and easy connects and disconnects. Design is similar to Plastic Quick couplings, but with high flow. They can be used for a variety of diverse applications and are interchangeable with many of Beiruote’s existing coupling lines, including the popular acetal quick couplings.

Materials:
Main components: 316 Stainless steel, Chrome-plated brass
Thumb latch: Stainless steel
Valves: Acetal PDFM
Valve springs: 316 Stainless Steel
O-ring: Buma-N, VITON
Color: Metallic luster
Pressure: Vacuum to 17.3 bar
Temperature: -40°C to 82 °C  ( the highest working temperature up to 204°Choose the high temperature )
Tubing Range: 1/8” to 3/8”, 3.2mm to 9.5mm

WARNING: Pressure, temperature, chemicals and operating environment can affect the performance of couplings.
